PR-1 Bias
Bias Agricultural Tyres
Construction BIAS
Service Tractor Service
New Deep Tread design for better wear and traction in mud
Increased lug bracing for high load durability
| Size | Ply rating | RIM | Section width | Overall diamter | Load capacity | Inflation pressure | Tread depth | Type | ||||
| mm | inch | mm | inch | kg | kPa | psi | mm | inch | ||||
| 7.50-16 | 8 | 5.50F | 195 | 7.7 | 890 | 35.0 | 700 | 240 | 35 | 70 | 88 | TT |
| 8.3-20 | 8 | W7 | 210 | 8.3 | 950 | 37.4 | 760 | 280 | 41 | 75 | 94 | TT |
| 9.5-24 | 8 | W8 | 240 | 9.4 | 1150 | 45.3 | 1510 | 280 | 41 | 80 | 101 | TT |
| 11/12.4-28 | 10 | W11 | 315 | 12.4 | 1293 | 50.9 | 2050 | 230 | 33 | 90 | 113 | TT |
