G-2
Radial Off-the-road Tyre
Consimuction BIAS
Service Loader and Earthmover Service
45° tread pattern design provides superior traction.
Proven tread pattern for increased traction on dirtand pavement.
Special tread compound enhances the wearing life.
| Size | Ply rating | TRA code | Rim | Section width (mm) | Overall diamter (mm) | Tread depth (mm) | 10km/h | 40km/h | Type | ||
| Load capacity（kg） | Inflation pressure（kPa） | Load capacity（kg） | Inflation pressure（kPa） | ||||||||
| 13.00-24 TG | 12 | G-2 | 8.00TG | 335 | 1280 | 24 | 5600 | 450 | 2725 | 300 | TL |
| 13.00-24 TG | 18 | G-2 | 8.00TG | 335 | 1280 | 24 | 6700 | 675 | 3500 | 450 | TL |
| 14.00-24 TG | 12 | G-2 | 8.00TG | 360 | 1350 | 24 | 6300 | 425 | 3075 | 275 | TL |
| 14.00-24 TG | 16 | G-2 | 8.00TG | 360 | 1350 | 24 | 7300 | 550 | 3650 | 350 | TT/TL |
