GR 9001

R-1/R-1W

Radial Agricultural Tyres

Construction RADIAL

Service Tractor Service

TECHNICAL DETAILS

Deeper R-w pattern increase the driving stability in mudor wet ground

Special designed curve of lug brings significantself-cleaning ability and improves drivability

Radial tire with lower pressure can reduce the soil com-paction significantly.

TRACTOR
SERVICE

TECHNICAL SPECIFICATIONS & APPLICATIONS

Size	Load index	Speed index	IND	Rim	Section width		Ovearall diameter		Load capacity	Inflation pressure		Tread depth		Type
Size	Load index	Speed index	IND	Rim	mm	inch	mm	inch	kg	kPa	psi	mm	32nds	Type
280/85R24	115/112	A8/B	R-1W	W10	282	11.1	1086	42.8	1215	160	23	39	49	TL
320/85R24	122/119	A8/B	R-1W	W11	319	12.6	1154	45.4	1500	160	23	41	52	TL
320/85R28	124/121	A8/B	R-1W	W11	319	12.6	1255	49.4	1600	160	23	41	52	TL
320/85R32	126/123	A8/B	R-1W	W11	319	12.6	1357	53.4	1700	160	23	41	52	TL
320/85R32	142/139	A8/B	R-1W	W11	319	12.6	1357	53.4	2650	400	58	41	52	TL
320/85R36	128/125	A8/B	R-1W	W11	319	12.6	1458	57.4	1800	160	23	41	52	TL
340/85R24	125/122	A8/B	R-1W	W12	343	13.5	1188	46.8	1650	160	23	42	53	TL
340/85R28	127/124	A8/B	R-1W	W12	343	13.5	1289	50.7	1750	160	23	42	53	TL
340/85R32	142/139	A8/B	R-1W	W12	343	13.5	1391	54.8	2650	360	52	42	53	TL
340/85R36	132/129	A8/B	R-1W	W12	343	13.5	1492	58.7	2000	160	23	42	53	TL
340/85R38	133/130	A8/B	R-1W	W12	343	13.5	1543	60.7	2060	160	23	42	53	TL
380/85R24	131/128	A8/B	R-1W	W12	380	15.0	1256	49.4	1950	160	23	45	57	TL
380/85R28	133/130	A8/B	R-1W	W12	380	15.0	1357	53.4	2060	160	23	45	57	TL
380/85R30	135/132	A8/B	R-1W	W12	380	15.0	1408	55.4	2180	160	23	45	57	TL
380/85R34	137/137	A8/B	R-1W	W12	380	15.0	1510	59.4	2300	160	23	45	57	TL
380/85R34	147/147	A8/B	R-1W	W12	380	15.0	1510	59.4	3075	300	44	45	57	TL
420/85R24	137/134	A8/B	R-1W	W15L	418	16.5	1324	52.1	2300	160	23	48	60	TL
420/85R28	139/136	A8/B	R-1W	W15L	418	16.5	1425	56.1	2430	160	23	48	60	TL
420/85R28	144/144	A8/B	R-1W	W15L	418	16.5	1425	56.1	2800	240	35	48	60	TL
420/85R30	140/137	A8/B	R-1W	W15L	418	16.5	1476	58.1	2500	160	23	48	60	TL
420/85R30	145/145	A8/B	R-1W	W15L	418	16.5	1476	58.1	2900	240	35	48	60	TL
420/85R34	142/139	A8/B	R-1W	W15L	418	16.5	1578	62.1	2650	160	23	48	60	TL
420/85R38	144/141	A8/B	R-1W	W15L	418	16.5	1679	66.1	2800	160	23	48	60	TL
460/85R30	145/142	A8/B	R-1W	W16L	455	17.9	1544	60.8	2900	160	23	51	64	TL
460/85R34	147/144	A8/B	R-1W	W16L	455	17.9	1646	64.8	3075	160	23	51	64	TL
460/85R38	149/146	A8/B	R-1W	W16L	455	17.9	1747	68.8	3250	160	23	51	64	TL
460/85R42	150/147	A8/B	R-1W	W16L	455	17.9	1849	72.8	3350	160	23	51	64	TL
460/85R46	152/149	A8/B	R-1W	W14L	464	18.3	1943	76.5	3550	160	23	51	64	TL
460/85R46	158/155	A8/B	R-1W	W14L	464	18.3	1943	76.5	4250	240	35	51	64	TL
520/85R38	155/152	A8/B	R-1W	DW16L	516	20.3	1849	72.8	3875	160	23	54	68	TL
520/85R38	160/160	A8/B	R-1W	DW16L	516	20.3	1849	72.8	4500	240	35	54	68	TL
520/85R42	157/154	A8/B	R-1W	DW16L	516	20.3	1951	76.8	4125	160	23	54	68	TL
520/85R42	167/164	A8/B	R-1W	DW16L	516	20.3	1951	76.8	5450	320	46	54	68	TL
420/80R46	145/142	A8/B	R-1W	W13	418	16.5	1840	72.4	2900	160	23	47	59	TL
420/80R46	151/148	A8/B	R-1W	W13	418	16.5	1840	72.4	3450	240	35	47	59	TL
480/80R42	151/151	A8/B	R-1W	DW16L	479	18.9	1835	72.2	3450	160	23	49	62	TL
480/80R42	156/156	A8/B	R-1W	DW16L	479	18.9	1835	72.2	4000	240	35	49	62	TL
480/80R46	158/158	A8/B	R-1W	DW16L	479	18.9	1936	76.2	4250	240	35	49	62	TL
420/90R30	142/139	A8/B	R-1W	DW13	418	16.5	1518	59.8	2650	160	23	48	60	TL
420/90R30	147/144	A8/B	R-1W	DW13	418	16.5	1518	59.8	3075	240	35	48	60	TL
320/90R46	146/143	A8/B	R-1	W10	319	12.6	1744	68.7	3000	320	46	37	47	TL
320/90R46	148/148	A8/B	R-1	W10	319	12.6	1744	68.7	3150	360	52	37	47	TL
